Photo Series Product Name Download Inductance
(uH) 		RDC(Ω) Isat(A) Irms(A) SRF
(MHZ)
MIN 		Select
Typ. Max Typ. Max Typ. Max

ME30151R0N

1.0 0.040 0.048 2.35  2.10 2.35 2.10 145

ME30151R5N

1.5 <P>0.055 0.066< P> 2.00&nbsp; 1.80 2.10 &nbsp; 1.90 130

ME30152R2M

2.2 0.060 0.072 1.65 1.48 1.80 &nbsp;1.60 90

ME30153R3M

3.3 0.093 0.112 1.40 1.21 1.60 &nbsp;1.45 75

ME30154R7M

4.7 0.113 0.136 1.20 1.08 1.40 1.25 65

ME30156R8M

6.8 0.176 0.211 1.05 0.90 1.10 0.90 50

ME3015100M

10 0.234 0.276 0.88 0.75 1.00 0.87 45

ME3015150M

15 0.352 0.422 0.68 0.58 0.80 0.65 33

ME3015220M

22 0.510 0.622 0.58 0.47 0.60 0.55 28

ME3015330M

33 0.799 &nbsp;0.959 0.46 0.39 0.50 0.45 22

ME3015470M

47 1.172 1.406 0.38 0.32 0.40 0.40 18

ME3015101M

100 2.433 2.920 0.27 0.23 0.29 0.25 11
